Designed to replace hydraulic systems while providing higher dynamic performance and improved efficiency, with a 46% increase in performance or previous design. These systems offer precise force and displacement control for single-axis durability, fatigue, and structural testing across a range of components and materials.

The seaPLUS series Load Frames are comprised of five standard models with peak dynamic forces of 13kN, 27N, 40kN, 54kN, and 108kN. Coupled with our integrated Static Load Support the full dynamic force range is available in addition to a static load offset, further increasing the total force capacity of the test stands.

The servoelectric actuator modular structure allows the upper columns, crosshead, and adjustment mechanisms to be configured for specific testing requirements without altering actuator performance. Our Load Frames utilize digital control with real-time feedback for force, velocity, and displacement; enabling stable closed-loop operation, high repeatability, and long-duration testing with reduced maintenance and energy consumption compared to hydraulic systems.
